production process:
Columns using stamping molding, according to the required size cut; beams according to the size of the raw materials selected through the mold roll forming, according to the required size cut;
The platform Panels adopt one-piece molding process, in collocation with reinforcing bars spot welded under the Panels to enhance the bearing capacity of the steel plate;
The parts that have been processed, will need to be welded together for welding, such as shelf columns and foot pieces, beams and grippers and so on. This needs to be welded according to the relevant national standards, to ensure that the welding strength and tolerance, welding is completed, the welded joints should be polished, to enhance the beauty of the shelves to improve the safety of the use of shelves;
Thickened shelves surface treatment using shot blasting machine surface rust, oil removal, and then by electrostatic powder spraying treatment, the surface is more smooth and beautiful not easy to oxidize, according to the customer's specified color spraying.
product features:
1. Multi-purpose, stores, factories, warehouses, families can build platforms, better use of space;
2. steel columns as the structural support of the platform, the steel platform is more stable than the attic; it is used to build the primary and secondary beams to be more robust than the attic shelves. because the steel platform is a steel columns (H-beam and other profiles) as a structural support for the entire platform, so in the use of the process of the steel platform in the firmness and safety of the platform is slightly more superior! The platform shelf floor is usually galvanized sheet.
3. The biggest feature of the steel structure platform is the fully assembled structure, the floor plate is locked by the locking device between the floor plate and the floor plate, the floor is flat, strong integrity, low cost and fast construction. It can be flexibly designed into 2-3 layers according to different site conditions, site requirements, functional requirements and logistics requirements, making full use of space.
4.with large carrying capacity, flexible design, easy to use, easy to install features, widely used in workshops or warehouses in the area, effectively increase the warehouse capacity, suitable for stacking placed items placed on the top of the platform can run pallet trucks, etc., the design of the load-bearing capacity is generally less than 1,000kg per square meter. It can be equipped with hydraulic lifting platform, ladder or forklift to access the goods, and can be designed as a steel structure platform with two or more floors for higher warehouses.
Packing method and shipment:
Our regular packing method is pallet packing, and we can pack the products according to customers' requirements.
Cargo transportation is mainly by sea; Qingdao port is the 3rd largest port in China, which can be quickly transported to every country.
Platform shelf product parameters: (unit mm)
Upright: 60*80*1.5mm, 60*80*2.0mm, 70*90*1.5mm, 70*90*2.0mm, 70*100*2.0mm, 70*100*3.0mm, 95*120*2.0mm, 95*120*2.5mm;
Crossbeam: 50*80*1.5mm, 50*100*1.5mm, 50*120*1.5mm, 50*140*1.5mm, 50*160*1.5mm, 50*180*1.5mm, hold welded beam;
Beam: 50*80*1.5mm, 50*100*1.5mm, 50*120*1.5mm, 50*140*1.5mm, hold weld beam;
Panel: 1.5mm, 2.0mm;
Color: blue, orange red, white, etc.
Conventional size: (unit mm)
Length: customized production as required;
Width: customized according to the need;
Height: customized according to need;
Number of layers: customized according to the needs of production;
Customized production and colors are available according to customer's needs;
Factory Introduction:
- The company currently has 4 standardized workshops, 28000 square meters of production plants, and 20 automated production lines. Due to the increase in export business of storage shelves, we have set up a 10000 square meter branch in Qingdao to better serve our customers, located close to the Qingdao Port terminal, saving delivery time and transportation costs for our customers;
- Intelligent automation control is implemented for all key production processes to meet various quality assurance requirements; This product has been exported to over 50 countries and received unanimous praise from all customers;
- Provide high-quality materials that meet international standards to ensure the load-bearing capacity and stability of the shelves, and meet long-term usage needs.
 |
 |
FAQ:
Q: Are you a factory or a trading company?
A: We are factory. We specialize in producing all kinds of storage shelves, heavy duty shelves, exhibition shelves, supermarket shelves and customized type shelves!
Q: Where is your factory located?
A: Our factory is located in Qingdao, China, you can fly to Qingdao airport directly, we welcome you to visit us anytime and make a good job of picking you up!
Q: How can I know more about your company?
A: Please leave a message on the website and leave your email or phone number, the company will send you the catalog by email or call you directly; also can intercommunicate with the video to take you on a site visit; also welcome to visit our company!
Q: How is the solidity and durability of the shelves?
A: The safety index of the shelves is very high, and there will not be any safety hazards!
Q: Whether the appearance of the shelf design can be customized according to demand?
A: Can be customized, we have a professional design team in accordance with customer requirements for the appearance of the design!
Q: Shelf size can be customized?
A: Can be customized, we can design and customize according to customer requirements!
